JY senes single-phase capacitor start induction motor is widely used in air compressors．refrigerators．medical apparatus

and other small machines which demand full-load starting，a large starting torque and Iimitted starting current．

These series motors are of totally enclosed fan．cooled，and have three frame sizes，09，1,2

The frames are made of cast iron or cast aluminium according to the requests.

Operating Conditions

Ambient temperature : -15040
Altitude: Not exceeding 1000 meters
Cooling type: IP44/IP54
Insulation class: B/F
Rated frequency: 50HZ/60HZ
Duty/Rating: Continuous (S1)
