Applications
For water supply from wells or reservoirs.
For domestic use.
For civil and industrial applications.
For garden using and irrigation.
Operating conditions
Maximum fluid temperature up to +55℃ .
Maximum sand content: 0.25%.
Maximum immersion :40m.
Minimum well diameter :4".
Motor and Pump
Rewindable motor or Full obturated screen motor
Three-phase: 380V-415V/50Hz
Single-phase: 220V-240V/50Hz
Equiped with start control box or digital auto-control box
Pumps are designed by casing stressed
NEMA dimension standards
Curve tolerance according to ISO 2548
